Electromagnetic Chuck
Product Description
The product is made of high-performance electromagnetic coils and high-quality magnetic materials, which generate a strong magnetic field through electricity. It can quickly adsorb steel plates, steel, castings, and other ferromagnetic workpieces, achieving safe and convenient lifting operations.
The electromagnetic suction cup has a compact structure and is easy to operate. It can be adsorbed and released by controlling the power supply, reducing manual hooking operations and improving work efficiency and safety. It has the characteristics of strong suction, stable load-bearing, and wide adaptability, making it an ideal magnetic lifting and handling equipment in modern industry.
Product Application
Electromagnetic Chuck are widely used in steel processing, machinery manufacturing, warehousing and logistics, mold processing, and heavy industry fields. They are mainly used for lifting and relocating magnetic metal materials such as steel plates, steel pipes, profiles, and cast iron parts. In steel plants and metal processing workshops, large steel plates, billets, and metal components can be quickly adsorbed and transported, improving production and loading and unloading efficiency; In the mechanical processing industry, it can be used for machine tool loading and unloading, workpiece transfer, and large component handling, reducing manual operations. In warehouses, docks, and logistics facilities, electromagnetic suction cups can be used in conjunction with cranes, gantry cranes, and other equipment to achieve rapid loading, unloading, and stacking of steel. In addition, it can also be used for lifting operations of large steel structural components in industries such as shipbuilding, automobile manufacturing, and construction machinery. With the characteristics of firm adhesion, flexible operation, and high handling efficiency, electromagnetic suction cups can meet the safe lifting needs of magnetic materials in various industrial environments.
Product advantages
- Strong adsorption capacity and stable load-bearing capacity
- Easy to operate, efficient and convenient
- Reduce material damage
- Easy to maintain, economical and practical
Product Specifications
| Model | MW5-70 | MW5-80 | MW5-90 | MW5-100 | MW5-110 | MW5-120 |
| Overall Dimensions A (mm) | 700 | 800 | 900 | 1000 | 1100 | 1200 |
| Overall Dimensions B (mm) | 800 | 1000 | 1090 | 1090 | 1140 | 1180 |
| Overall Dimensions C (mm) | 160 | 160 | 200 | 200 | 220 | 220 |
| Overall Dimensions D (mm) | 90 | 90 | 125 | 150 | 150 | 150 |
| Overall Dimensions E (mm) | 30 | 30 | 40 | 45 | 45 | 45 |
| Weight (kg) | 570 | 680 | 820 | 994 | 1196 | 1380 |
| Rated Voltage (V) | 235 | 631 | 4 | 5 | 6 | 7 |
| Cold Current (A) | 11.6/7.6 | 14.1/9.2 | 21.3/13.6 | 24.4/15.8 | 27.7/18 | 33.6/21.9 |
| Power (kW) | 2500 | 3000 | 4000 | 5500 | 6500 | 7500 |
| Steel Plate Lifting Capacity (kg) | 380/200 | 480/250 | 600/400 | 750/500 | 1000/800 | 1200 |
| Cast Iron Lifting Capacity (kg) | 120/100 | 150/130 | 250/200 | 350/300 | 450/400 | 600 |
| Control Cabinet Size (cm) | 110×60×38 | 110×60×38 | 110×60×38 | 110×60×38 | 110×60×38 | 110×60×38 |
| Control Cabinet Weight (kg) | 46 | 46 | 46 | 46 | 46 | 46 |
| Cable Reel Weight (kg) | 75 | 75 | 75 | 75 | 75 | 75 |
| Cable Specification (mm²) | 2×10² | 2×10² | 2×10² | 2×10² | 2×10² | 2×10² |
| Total Weight (kg) | 691 | 801 | 941 | 1115 | 1317 | 1501 |
Products Details
Fully sealed structure with no leakage
The structure of the electromagnet is simple, compact, firm, and reliable, with strong adaptability to fully sealed environments
The compact size can generate strong adsorption force
Simple control, labor-saving, energy-saving, safe and reliable, and can be remotely operated
